RED certification is one of the EU's mandatory CE certification modes for wireless product certification. Products with wireless transmission frequencies such as wireless doorbells, Bluetooth devices, wireless routers, WiFi devices, wireless alarm devices, radio receiving and transmission equipment, telephones , computers, etc., all need to apply for RED certification.
CE-RED certification is referred to as Red certification (European wireless product certification), and the purpose is that wireless products in Europe must pass this test certification. The CE (Conformite Europeenne, European unification) mark is a safety certification mark and is regarded as a passport for manufacturers to open and enter the European market. In the EU market, the CE mark is a compulsory certification mark. All products with the CE mark can be sold in the member states of the European Union (EU CE certification) without meeting the requirements of each member state, so that the goods can be sold in the EU member states. free circulation within.
Wireless CE-RED Product Certification Scope
1. Short-distance wireless remote control products (SRD) such as: remote control toy cars, remote control alarm systems, remote control doorbells, remote control switches, remote control mice, keyboards, etc.;
2. Professional radio remote control products (PMR) such as: professional wireless walkie-talkies, wireless microphones, etc.;
3. Wireless phone CTO, CT1, CT1+…;
4. ISDN (digital telephone products);
5. DECT (enhanced digital wireless telephone);
6. Mobile phone GSM.CDMA test;
7. Bluetooth products such as: Bluetooth headset;
8. Inductive data transmission equipment with a working frequency of 9kHz;
9. Wireless broadcast receiving equipment.
CE-RED certification testing standard
Electrical Safety (LVD): EN 62368-1:2014+A11:2017
Electromagnetic Compatibility (EMC): EN 301489-1 V2.2.3 (General), EN 301489-17 V3.2.0 (Bluetooth, WALN)
Radio Frequency (RF): EN 300328 V2.2.2
Health (SAR): EN 62479:2010 (or EN 50663:2017, less than 20mW can be excluded)
CE-RED certification test project
1. Electromagnetic compatibility test (EMC test)
2. Safety test LVD (in the new directive, this test is also required for RF products with battery input)
3. Radio communication equipment test (RF test) according to European ETSI standard
4. Notification of Spectrum Allowed in Europe
5. CTR (TBR) test
6. Electrical safety and health protection test (SAR assessment)
Materials to be prepared for wireless CE-RED certification application
1. User Manual
2. Circuit schematic
3. Circuit block diagram (Block Diagram, also called module function diagram)
4. Circuit wiring diagram (PCB LAYOUT)
5. PCB placement
6. Operation description (explanation of block diagram)
7. Component list (BOM LIST)
8, label (label)
9. Antenna specifications (or antenna gain diagram)
10. Charger LVD report
11. Fixed frequency software (also called fixed frequency program. It enables the transmitter module to continuously transmit at a certain frequency. Generally, BT and WIFI must be provided)
Wireless CE-RED certification process
1. Project application - submit an application for CE certification to the supervision of the testing agency.
2. Data preparation - According to the CE certification requirements, the enterprise prepares the relevant certification documents.
3. Product testing - the company sends the samples to be tested to the laboratory for testing.
4. Preparation of reports - certified engineers prepare reports based on qualified test data.
5. Submit for review - the engineer will review the complete report.
6. Issuing a certificate - CE certification will be issued after the report is reviewed and verified.
Please contact our company ZRLK for wireless CE-RED certification. We will provide you with professional and efficient testing and certification services with favorable prices and considerate service. If you provide us with product pictures and specifications, we will give you corresponding cycles, quotations and specific solutions according to your products. You are welcome to inquire!
